The combination of various products in our range that provide solutions to the most common needs in pneumatics / electropneumatics.
| • SAI7378 |
Pneumatics / electropneumatics pack |
Este pack de neumática / electroneumática está diseñado para:
• Aquire knowledge.
• Design and simulate the circuits.
• Test and operate the real circuits with more than 30 activities available.
 Composition of the pack (SAI7378)
| Part Number |
Description |
Qty. |
| SAI2065 |
Rolling table with twin-post |
1 |
| SAI2074 |
Drawer unit for rolling table with lock |
2 |
| SAI4-2285 |
PNEU-405: Pneumatics - electro-pneumatics kits |
2 |
| SAIU020-001 |
SINGLE USE licence for the eLEARNING-200 pack of courses |
6 |
| SAI2252 |
AutoSIM-200, 1 educational license |
2 |
| SAI7376 |
Poster of the composition PNEU-405 |
1 |
List of activities for PNEU-405
| PNEUMATICS |
| • Direct control of a single acting cylinder. |
| • Indirect control of a single acting cylinder. |
| • Indirect control of a double acting cylinder. |
| • Control of a double acting cylinder with bistable valve. |
| • Control of a double acting cylinder from two independent locations. |
| • Control of a double acting cylinder from two simultaneous locations. |
| • Regulation of the speed of a double acting cylinder. |
| • Increase in the speed of a double acting cylinder. |
| • Memory function with a monostable valve. |
| • Detection and control of the position of a cylinder. |
| • Delay in a control signal. |
| • Activation of a control signal according to the pressure. |
| • Stamping device. |
| • Frame press. |
| • Holding device. |
| • Stamping wooden parts. |
| • Distribution of boxes. |
| • Control of casting ladle. |
| • Warehouse clearance. |
| • Distribution and separation of parts. |
| ELECTROPNEUMATIC |
| • Single control of a single acting cylinder with a monostable electrovalve. |
| • Single control of a double acting cylinder with a monostable electrovalve. |
| • Control of a single acting cylinder with bistable electrovalve. |
| • Control of a double acting cylinder with bistable electrovalve. |
| • Control with a monostable electrovalve, with bistable effect (memory). |
| • Detection and control of the position of a double acting cylinder with mechanical stroke limiters. |
| • Detection and control of the position of a cylinder with magnetic detectors. |
| • Sequence with choice of single or continuous cycle. |
| • Transfer of packets. |
| • Riveting device. |
Complete laboratory
Proposal for the pneumatics / electropneumatics complete laboratory: 4 stations with 2 workstations (up to 24 students).
| • SAI7379 |
Complete laboratory - pneumatics / electropneumatics
|
• Composition for the complete laboratory (SAI7379):
| Part Number |
Description |
Qty. |
| SAI7378 |
Pneumatics / electropneumatics pack |
4 |
| SAI2254 |
AutoSIM-200, 16 educational licenses |
1 |
| SAI7377 |
Posters of symbols |
1 |
| SAI7343 |
Pneumatic magnetic symbols kit |
1 |
|
